| Electrics |
| 001 |
3x 400 V motor voltage, 50 Hz motor frequency |
S |
| 002 |
3x 230 V motor voltage, 60 Hz motor frequency |
O |
| 29 |
CSA certificate |
O |
| 77 |
Tempora air conditioning unit (for continuous external conditions of over 40° C) |
O |
| 25 |
Multi-voltage 3x400V-230V and 50-60Hz (#001 + #004) |
O |
| |
| Working dimensions |
| |
Min. workpiece width (mm) *The minimum workpiece width varies depending on the workpiece length, height and type of surface |
70 |
| |
Min. workpiece length (mm) |
140 |
| |
Min. workpiece height (mm) |
8 |
| |
Max. workpiece height (mm) |
45 |
| |
Processing of 0.4–3.0 mm coiled material |
S |
| |
| Units |
| |
Control with 15” Touch Screen display, integrated maintenance software and network connection |
S |
| 80 |
Edge thickness measurement using Bluetooth transfer device |
O |
| 76 |
Fan for electric box |
O |
| 72 |
Recording of operating hours for several users |
O |
| |
Solid steel machine chassis |
S |
| |
Pull-out workpiece support of 450 mm – facilitates working with large workpieces |
S |
| |
Manual height adjustment of the workpiece feed pressure rollers with 2 offset lines of rollers for equal pressure distribution on the workpiece |
S |
| |
Chain feed with a 9 m/min feed speed and rubber covered pads for optimum grip of the workpiece |
S |
| 64 |
Pneumatic-mechanical infeed gate, to prevent the premature feeding of the workpiece |
O |
| |
750 mm diameter coil support, running on ball bearings |
S |
| 46 |
Extended infeed guide and table size |
O |
| |
Premilling unit with activation controlled diamond cutters and 2 independent motors each with 0,75 kW, 12,000 rpm |
S |
| 44 |
Reduced price for tempora 45.03 without premilling unit |
O |
| 47 |
Premillers with replaceable cutters 49 mm in height (!44) |
O |
| 43 |
Infrared heat lamp for pre-heating board edges |
O |
| |
Edge feed for coiled and strip material 0.4–3.0 mm in thickness |
S |
| |
Guillotine trimming unit for the precutting of PVC/ABS edgeband material 0.4–3.0 mm thick |
S |
| |
Teflon coated gluepot with 1.5 kg capacity, glue applied using a glue roller as well as monitoring of the heating cartridge |
S |
| 63 |
easy-clean cleaning device for the standard gluepot |
O |
| |
Manually adjustable pressure roller unit with 1 large pressure roller and 1 rubber post-pressure roller, mechanically tensioned |
S |
| |
m-motion end trimming unit with linear movement and 1 motor 0.35kW, 12,000 rpm. |
S |
| 48 |
m-motion end trimming unit with 45° movement with 1 motor 0.35 kW, 12,000 rpm |
O |
| 49 |
m-motion end trimming unit with 45° movement and radius processing with 1 motor 0.35 kW, 12,000 rpm |
O |
| |
m-motion multifunction trimming unit for radius, flush and bevel trimming of thin edges with 2 independent motors each with |
S |
| 51 |
Multi-functional trimming unit with vertical reference rollers for the processing of workpieces with hinge bores (#64) |
O |
| |
Single-motor corner rounding unit for post and soft form profiles up to 45mm |
S |
| 66 |
Changeable gluepot F400 instead of the standard application unit |
O |
| 50 |
Additional changeable gluepot (#66) |
O |
| |
| Finishing units |
| |
m-motion Radius scraping unit for R= 2 mm, manual activation, mechanical setup |
S |
| 20 |
Glue scraping unit, mechanically controlled |
O |
| |
Buffing unit with 2 motors |
S |
| 30 |
Buffing unit "texture finish" for both flat and structured surfaces incl. additional spraying unit instead of a standard buffing unit |
O |
| 32 |
Spraying unit for cleaning agent postitioned before buffing unit (only in combination with the buffing unit) |
O |
| 42 |
Spraying unit of releasing agent on the machine infeed side (PUR glue) (!44) |
O |
| 53 |
Spraying unit of lubricantion agent |
O |
| 87 |
Omission of spray liquids |
W |
| 88 |
Jowat type adhesive incl. 2 kg adhesive granulate |
W |
| |
| Tailor made equipment options |
| 81 |
Tool preparation R= 1 mm instead of R= 2 mm |
W |
| 86 |
Tool preparation R= 1.5 mm for corner rounding unit (!68) |
W |
| 83 |
Tool preparation R= 3 mm instead of R= 2 mm |
W |
| 33 |
LED lighting |
O |
| |
| Packages |
| 75 |
"x-motion PLUS" package tempora F 400 45.03 "x-motion PLUS" control with 18" smartouch instead of 15" touch screen |
O |
| |
| Important Accessories |
| |
200-106 - Mobile cleaning unit for the glue pot including a temperature regulator initiator for the glue rollers, including a pre-melting function |
O |
| |
200-107 - Storage bins for the glue pot, including an air condenser for PUR glue |
O |
| |
202-122 - storEdge edge storage including support plate |
O |
| |
202-123 - storEdge edge storage without support plate |
O |
| 210 |
Rolling carriage |
O |
| |
202-129 - puReady nitrogen container |
O |
| |
220-128 - Silicon gluepot insert F600 / F400 |
O |
| |
Changeable gluepot tempora series |
|
| |
220-100 - Changeable gluepot for tempora 45.03/ 60.06 for 1.5kg EVA granulate, Teflon coated |
|
| |
| Transport |
| 229 |
Container packaging |
O |
