| Electrics | ||
| 001 | 3x 400 V motor voltage, 50 Hz motor frequency | S |
| 002 | 3x 230 V motor voltage, 60 Hz motor frequency | O |
| 29 | CSA certificate | O |
| 77 | Tempora air conditioning unit (for continuous external conditions of over 40° C) | O |
| Working dimensions | ||
| Min. workpiece width (mm) *The minimum workpiece width varies depending on the workpiece length, height and type of surface | 70 | |
| Min. workpiece length (mm) | 140 | |
| Min. workpiece height (mm) | 8 | |
| Max. workpiece height (mm) | 60 | |
| Processing of 0.4–3.0 mm coiled material | S | |
| Processing of 0.4–12 mm strip material | S | |
| Units | ||
| "E-motion plus" control with 18" Touch Screen display with integrated maintenance software and network connection available | S | |
| 80 | Edge thickness measurement with Bluetooth transmission device (!80A) | O |
| 80A | Edge and workpiece thickness measurement (!80) | O |
| 76 | Fan for electrical control box | O |
| 72 | Recording of operation hours for several users | O |
| 72A | Dynamic program change for pressure bars | O |
| Solid steel machine chassis | S | |
| Pull-out workpiece support - to assist in the processing of larger workpieces | S | |
| 23 | Additional swiveling workpiece holder | O |
| Motor driven adjustment of the workpiece feed pressure rollers with 2 offset lines of rollers for equal pressure distribution | S | |
| Chain feeder with a speed of 12 m/min and rubber grip pads, for maximum grip on the workpiece | S | |
| 59 | Automatic lubrication for guideways chain conveyors (!60) | O |
| 60 | Chain feed with 12 and 20 m / min feed speed and rubber covered pads for optimum grip of the workpiece | O |
| 64 | Pneumatic-mechanical infeed gate, to prevent the premature feeding of the workpiece | O |
| 770 mm diameter coil support, running on ball bearings | S | |
| Feeding guide with rollers for processing fragile material | S | |
| 46 | Extended infeed (+ 400 mm) | O |
| 48 | Air cushion table with blower as workpiece support (#46) | O |
| 49 | additional air cushion table with extendable workpiece support (#48 / #46) | O |
| 89 | Angle stop for narrow parts (#48) | O |
| 41 | Premilling unit with two 1.5 kW independant motors running at 12,000 rpm and diamond tipped cutters, motor driven | S |
| 44 | Reduced price for tempora 60.12 without premilling unit | O |
| 45 | Premilling, 64 mm instead of 49 mm, 2 motors with 2.2kW each instead of 1.5kW each | O |
| 47 | Premillers with replecable cutters 64 mm in height instead of 49 mm (!44/!45) | O |
| 43 | Infrared heat lamp for pre-heating board edges | O |
| Edge feed for coiled and strip material 0.4 - 12 mm thick, with edge presence recognition via an infra-red sensor | S | |
| Guillotine trimming unit for the precutting of PVC/ABS edgeband material from 0.4 - 3.0 mm thick | S | |
| Teflon coated gluepot with 1.5 kg capacity, glue applied using fine-adjustable glue roller and quick change system | S | |
| 65 | Preparation for retrofitting a premelter (!66) | O |
| 66 | Premelter for glue granulate, 3.5 kg capacity; 0.4 kg glue pot with glue level sensor and quick change system, heated glue | O |
| 67 | Reverse function of the glue applicator roller | O |
| 50 | Additional changeable gluepot (!67) | O |
| 50A | Additional changeable gluepot reverse operation (#67) | O |
| 73 | Pneumatically feed-controlled glue unit | S |
| 63 | easy-clean cleaning device for the standard gluepot | O |
| Motor driven postitioning of the pressure unit with 1 large motor driven roller and 2 conical rollers operating pneumatically | S | |
| 70 | End trimming unit with 2 independant motors, each with 0.50 kW and 12,000 rpm, both pneumatically tiltable | S |
| Multi functional trimming unit for radius and flush trimming and bevel trimming of thin edges with 1 independant motors | S | |
| 51 | Multi-functional trimming unit with vertical reference rollers for the processing of workpieces with hinge bores (#64) | O |
| 90 | classic multifunctional milling and radius scraper unit e-motion with radius 1 and 2 mm | O |
| 69 | Corner rounding unit for soft- and post forming pieces for processing edges of between 0.4 and 3.0 mm in thickness |
S |
| 68 | Corner rounding unit with 2 independant motors for soft and postforming workpieces and for the processing of front and rear | O |
| 78 | Changeable copy roller for the motor corner rpunding unit for edge thickness 1.5mm (#68) | O |
| 71 | Motor adjustment and positioning of courner-rounding cutters | O |
| 56 | advantEdge aggregate for the processing of co-extruded edge material up to 40mm workpiece height | O |
| 58 | external bag melter for the processing of PUR-glue on the machine | O |
| Finishing units | ||
| 11 | 2-axis, motor-driven, position-controlled radius trimming unit incl. pneumatic reverse function | S |
| 20 | Glue scraping unit, pneumatically controlled | O |
| 21 | Glue scraping for nesting (!20) | O |
| 30 | Buffing unit with 2 motors | S |
| 30 | Bufifng unit "texture finish" for both flat and structured surfaces incl. additional spraying unit instead of a standard buffing unit | O |
| 32 | Spraying unit for cleaning fluids situated before the polishing units | O |
| 42 | Spraying unit for separation solution positioned at the front of the | O |
| 52 | Sprating of anti-static agents | O |
| 53 | Spraying of lubricants | O |
| 74 | Grooving unit for horizontal or vertical processing, motorised adjustment X+Y axis, limitation on the corner rounding unit 10- | O |
| 87 | Omission of spray liquids | W |
| 88 | Jowat type adhesive incl. 2 kg adhesive granulate | W |
| Tailor made equipment options | ||
| 33 | Led lighting | O |
| 81 | Tool preparation R= 1 mm instead of R= 2 mm | W |
| 86 | Tool preparation R= 1.5 mm instead for corner rounding unit (!68) | W |
| 83 | Tool preparation R= 3 mm instead of R= 2 mm | W |
| 86A |
Tool preparation R= 1.5 mm for 2 motorized corner rounding units (#68) |
W |
| Important accessories | ||
| 505 | Extraction distributor professional (!56) | O |
| 500 | 02.0.202 - distributor for extraction T60.12 and 1x 02.0.1616 fastening pack and 2x02.0.010 hose clamp D-120 mm | O |
| 502 | 02.0.412 - H/SE-Industrial Dust reinforced D=120 mm | O |
| 501 | 02.0.406 - H/SE-Industrial Dust reinforced D=60 mm | O |
| 200-102 - Filter unit with water seprator and two fine upstream filters with contamination indicators for maintenance unit | O | |
| 200-105 - Additional support frame for edgebaners with a length of 2100 mm. The height is adjustable from 870 to 960 mm | O | |
| 200-106 – Mobile cleaning unit for the glue pot including a temperature regulator initiator for the glue rollers | O | |
| 200-107 – Storage bins for the glue pot, including an air condenser for PUR glue | O | |
| 202-122 - storEdge edge storage including support plate | O | |
| 202-123 - storEdge edge storage without support plate | O | |
| 202-129 puReady nitrogen container | O | |
| 202-139 - Silicon gluepot insert F800 | O | |
| Transport | ||
| 229 | Container packaging | O |
| U-motion classic return system | ||
| 603 | Return feeding without rotation function for workpieces; length 300-2800 mm; width 80-1300 mm; thickness 8-60mm | O |
| 620 | Mechanical rotation function of the workpieces on the conveyor belt | O |
| 621 | Ergonomics package incl. air cushion lifting table instead of outfeed roller conveyor as well as an air cushion connection table to the machine | O |
| U-motion professional return system | ||
| 605 | Returning with rot. function for workpieces | O |
| 621A | Ergonomics package incl. air cushion lifting table instead of outfeed roller conveyor as well as an air cushion connection table | O |
| U-motion professional return system options | ||
| 90 | additional loading position 1200mm (max. 1 piece) (#84) | O |
| Preparation of U-motion System | ||
| 84 | u-motion classic preparation (!85) | O |
| 85 | u-motion professional preparation (!84) | O |
| S | ... | Standard equipment |
| O | ... | Option |
| W | ... | Optional equipment at no extra cost |
| - | ... | Not available |
