| Electrical setup | ||||
| 001 | 3x 400 V | S | ||
| 002 | 3x 230 V motor voltage | W | ||
| 003 | 1x 230 V, motor power 4.0 HP (3.0 kW)* | O | ||
| 004 | 50 Hz | S | ||
| 005 | 60 Hz | W | ||
| 3.0 HP (2.2 kW) | S | |||
| 10 | Anti-static filter | O | ||
| General | ||||
| Max. airflow m³/h | 2500 | |||
| Nominal air flow capacity 20 m/sec. m³/h | 1108 | |||
| Static pressure Pa | 2200 | |||
| Dimensions mm (L x W x H) | 1040 x 898 x 1940 | |||
| Filter surface area m² | 10 | |||
| Extraction connector Ø in mm | 140 | |||
| Dust emission quality mg/m³ | <0,1 | |||
| Acoustic pressure dB | 74 | |||
| Chip volume litres | 200 | |||
| Weight kg (with standard configuration) | 220 | |||
| Automatic Start | ||||
| 02.0.340 - Automatic Start for 1-8 Machines | O | |||
| 02.0.345 - Automatic Start for 1-8 Machines and 8 electric gates | O | |||
| 02.0.344 - Automatic Start for 1-8 Machines and 8 electric gates, freely programmable | O | |||
| 02.0.346 - Transformer Coils for Automatic Start | O | |||
| Important Accessories | ||||
| 223 | IPPC | O | ||
| 02.0.036 - Waste Bags, 10 Pieces (740/630 x 1300 x 0.15) | O | |||
*) Power rating S6/40%
