| STANDARD EQUIPMENT |
| Integrated control |
| Industrial PC Windows XP Embedded, developed by CNI. |
| 15” colour monitor, CD, keyboard and mouse. |
| ILENIA CAD -CAM 4 software. USB connection. |
| Panel supports forward and backward (1200x400 mm) |
|
Max. dimensions of the workpiece |
3200 x 1020 x 50 mm |
| Min. dimensions of the workpiece | 300 x 120 x 8 mm |
| Interaxis between spindles | 32 mm |
| Diameter max boring | 35 mm |
|
N° controlled axes |
4 (x, y, z-, w) |
| Max boring depth | 50 mm |
|
N° controlled axes x |
42 m/min |
| N° controlled axes y | 42 m/min |
| N° controlled axes z- | 10 m/min |
| N° controlled axes w | 5m/min |
|
Spindle-rotation speed |
3200 rpm |
|
Total Power |
3 Kw |
| Working air pressure | 6-8 bar |
| Standard air pressure consumption | 20 l/cycle |
| Overall dimensions | 2200 x 1500 x 1250 mm |
| Height of the working table | 900 mm |
| Net/gross weight | 1200 / 1350 kg |
