G 560
|
||||
|
|
Electrical setup
|
|||
|
001
|
3x 400 V
|
S
|
||
|
004
|
50 Hz
|
S
|
||
|
005
|
60 Hz
|
W
|
||
|
|
Multi-voltage input 3x190V / 208V / 230V / 400V / 415V / 440V / 480V
|
O
|
||
|
|
||||
|
|
Working dimensions
|
|||
|
|
Edge thickness min.–max. (mm)
|
0,4–5,0
|
||
|
|
Work piece thickness min.–max. (mm)
|
8-50
|
||
|
|
Min. workpiece width (mm) The minimal workpiece width varies depending on the workpiece length, height and type of surface
|
70
|
||
|
|
Min. workpiece length (mm)
|
140 | ||
|
|
||||
|
|
Units
|
|||
|
|
3 free spaces for additional processing units
|
S
|
||
|
|
Control with 10.4” Touch Screen Display |
S
|
||
|
|
Chain feed with 9 m / min (10.8m /min at 60 hZ) feed speed and rubberized support pads for optimal holdon the workpiece
|
S
|
||
|
|
Container packaging |
S
|
||
|
|
Pull-out workpiece support of 450mm - facilitates working with large workpiece
|
S
|
||
|
|
Pneumatic disengaging mechanism of the radius scraping unit
|
S
|
||
|
|
Coiled edge band feed support plate Ø 720 mm, for PVC/ABS
|
S
|
||
|
|
Processing of coiled material in thick PVC/ABS from 0.4 to 3.0 mm in thickness; single feed of strip material up to 5mm is also possible
|
S
|
||
|
|
Guillotine shears for cutting coiled edge bands up to 3 mm in thickness in Hard-PVC/ABS |
S
|
||
|
|
Joining unit with application-controlled diamond milling cutters and 2 independent motors, each with 0.75 kW, 12,000 rpm, chip removal manually adjustable from 0â2 mm, incl. 2 diamond milling cutters (Ø 70 mm, H 54 mm, Z 2 2)
|
S
|
||
|
47
|
Joining cutter with interchangeable cutters
|
O
|
||
|
43
|
Infrared heating lamp for preheating the panel edge
|
O
|
||
|
|
Teflon coated gluepot with 1.5 kg capacity, glue applied using a glue roller as well as monitoring of the heating cartridge (approx. 250 running metres per 1kg glue granulate on a 19mm panel)
|
S
|
||
|
66
|
Changeable gluepot F400 instead of the standard application unit
|
O
|
||
|
|
Pressing unit is mechanically pre-stressed, 1 straight pressure roller and 2 additional pressure rollers |
S
|
||
|
|
End trimming unit with 2 independant motors, each with 0.55 kW and 12,000 rpm, both manually tiltable between 0°–10°
|
S
|
||
|
|
Multifunctional milling unit, 12,000 rpm, 2x 0.55 kW, radius milling, flush milling, chamfer milling for thin edges, adjustment by means of edge section |
S
|
||
|
90
|
Multiradius R1 R2mm on the multifunction milling unit
|
O
|
||
|
|
Single motor corner rounding unit for post and soft form profiles up to 50mm
|
S
|
||
